How do IMPA Marine Numbers Map to Phelps Industrial's Products

January 8th at 6:44pm

IMPA Marine stores coding/numbers are used in the marine industry to identify marine supplies world-wide. The IMPA system consists of a 6-digit code for marine products, and related products are grouped in product classes. Below table List the mapping of IMPA Numbers to the products that Phelps supplies to the marine industry.

Phelps has been serving the Marine industry with a wide range of best-in-class fluid sealing products. Phelps carries significant inventory of Compression Packing, Rubber Sheets, PTFE Packing Sheets, Graphite Packing Sheets for a quick turnaround.

Phelps is also listed as a supplier for IMPA/Marine Products on one of the largest Marine Procurement Portals: ShipServ

IMPA NumbersIMPA DESCRIPTIONPillar NumberPhelps Style Number
810221, 810222, 810223, 810224, 810225, 810226, 810227, 810228, 810229, 810230, 810231, 810232, 810233, 810234, 810235PACKING PTFE RAMIE PILLAR NO.426F426FPhelps Style 3010
810381, 810382, 810383, 810384, 810385, 810386, 810387, 810388, 810389, 810390, 810391, 810392, 810393, 810394, 810395PACKING UNIVERSAL CARBONIZED FIBER PILLAR NO.6501L6501LanPhelps Style 2024
810401, 810402, 810403, 810404, 810405, 810406, 810407, 810408, 810409, 810410, 810411, 810412, 810413, 810414, 810415PACKING PTFE FIBER PILLAR NO.4505L4505LPhelps Style 2033
810451, 810452, 810453, 810454, 810455, 810456, 810457PACKING ARAMID FIBRE NO.4526L ASBESTOS FREE4526LPhelps Style 2042
810472, 810473, 810474, 810475, 810476, 810477, 810478, 810479, 810480, 810481, 810482, 810483, 810484PACKING NON ASBESTOS WATER/OIL PILLAR NO.4516L4516LPhelps Style: 2042
810521, 810522, 810523, 810524, 810525, 810526, 810527, 810528, 810529, 810530, 810531, 810532, 810533, 810534, 810535PACKING NON ASBESTOS CHEMICAL PUMP PILLAR NO.4527L4527LPhelps Style 2024
810546, 810547, 810548, 810549, 810550, 810551, 810552, 810553, 810554, 810555, 810556, 810557, 810558, 810559, 810560PACKING NON ASBESTOS FOR PUMP PILLAR NO.67336733Phelps Style 2105
810565. 810566. 810567, 810568, 810569, 810570, 810571, 810572, 810573, 810574, 810575, 810576, 810577, 810578, 810579, 810580PACKING NON ASBESTOS WATER/OIL PILLAR NO.4506L4506LPhelps Style: 2172
810581, 810582, 810583, 810584, 810585, 810586, 810587, 810588, 810589, 810590, 810591, 810592, 810593, 810594, 810595PACKING NON ASBESTOS HI-TEMP HI-PRESSURE #67116711Phelps Style 2110
810701, 810702, 810703, 810704, 810705, 810706, 810707, 810708, 810709, 810710, 810711, 810712PACKING WATER LIGHTHOUSE NO.6767Phelps Style 3014
811025, 811026, 811027, 811028, 811029METAL FOIL INSERTED GRAPHITE SHEETSNonePhelps Style: 7503
811071, 811072, 811073, 811074, 811075, 811076JOINT SHT GASKET PILLAR #5611 NON-ASBESTOS5611Phelps Style: 7100
811079, 811081, 811082, 811083, 811084, 811085, 811086, 811088JOINT SHEET VEGETABLE FIBER OIL-PROOFnonePhelps Style: 7540
811111, 811112, 811113, 811114, 811115, 811116, 811117, 811118, 811119, 811120, 811121, 811122JOINT SHEET NATURAL RUBBERnonePhelps Style: 7106
811124, 811125, 811126. 811127, 811128, 811129Joint Seet Non-Asbestos Pillar No.56505650Phelps Style: 7075
811131, 811132, 811133, 811134, 811135, 811136, 811137, 811138, 811139, 811140, 811141, 811142JOINT SHEET SYNTHETIC RUBBERnonePhelps Style: 7106
811151, 811152, 811153JOINT SHEET COTTON-INSERTION RUBBERNonePhelps Style: CI-Rubber
811181, 811182, 811183, 811184, 811185, 811186, 811187, 811188, 811189, 811190, 811191, 811192, 811193, 811194, 811195, 811196, 811197, 811198, 811199JOINT SHEET FELTNonePhelps Style: 7650
811280, 811281, 811282, 811283, 811284, 811285SHEET PACKING NON-ASBESTOS #172172Phelps Style: 7010
811286, 811287, 811288, 811289Joint Sheet Expanded Graphite Novaphit SSTCNovaphit SSTCPhelps Style: 7505
811291, 811292, 811293, 811294, 811295, 811296SHEET PACKING NON-ASBESTOS #178178Phelps Style: 7100
811301, 811302, 811303, 811304, 811305, 811306, 811307, 811308, 811309, 811310, 811311, 811312PACKING UNIVERSAL NON-ASBESTOS PILOTPACK 80228022Phelps Style: 2072
811321, 811322, 811323, 811324, 811325, 811326, 811327, 811328, 811329, 811330, 811331, 811332PACKING PILOSTIL BELDAM CRSLY NO.81138113Phelps Style: 2075
811336, 811337, 811338, 811339, 811340, 811341, 811342, 811343, 811344, 811345, 811346, 81133647, 811348, 811349, 811350PILLARFOIL BRAIDED PACKING, (MARK VII) PILLAR NO. 61146114Phelps Style: 2105
811351, 811352, 811353, 811354, 811355, 811356, 811357, 811358RUBBER SHEET HYBRID ARAMID FIBER PLR#50035003Phelps Style: 7100
811361, 811362, 811363, 811364, 811365, 811366, 811367, 811368, 811369, 811370, 811371, 811372, 811373, 811374, 81175PILLARFOIL BRAIDED PACKING, (MARK V) PILLAR NO. 6315CL6315CLPhelps Style: 2110
811701, 811702, 811703CLOTH GLASSNonePhelps Style: 7700
811710, 811711, 811712, 811713, 811714, 811715TAPE GLASSNonePhelps Style: 7703
812531, 812532, 812533, 812534, 812535, 812536, 812537, 812541, 812542, 812543. 812544, 812545, 812546, 812547TEFLON SHEETNonePhelps Style: 7530
810451, 810452, 810453, 810454TEFLONCORDNonePhelps Style: 2440
812561, 812562, 812563, 812564, 812565, 812566TAPE JOINT SEALANT GORE-TEXNonePhelps Style: 1500


In addition to the above listed IMPA numbers, Phelps carries supplies Hatch Packing for tank lid & hatch cover, seals for cargo covers, and access ramp doors for many vessels including: Naval Ships, Cruise Ships, Ferry Lines, Oil & Gas and Chemical Tankers, Rail Cars.  Additionally, hatch packing is used for watertight doors, skylights, ullage plugs and other marine applications.

For more information, please call the Phelps staff @ 1-800-876-SEAL, or @ 1-800-348-9784
